H3C S3600 Series Ethernet Switches Chapter 1 Product Overview
1-7
Attribute Description
Service
z Connection to the ASCII terminal
z Connection to the serial interface of a local terminal (a PC for
example) or to a remote terminal through a pair of modems), where
terminal emulation program is run
V. Attributes of the 1000Base-X SFP ports
The S3600-28P-SI provides four 1000Base-X SFP ports (numbered from 25 to 28) on
its front panel.
SFP modules allow for great flexibility because they are hot swappable and user
configurable.
Table 1-5 lists the available SFP modules.
Table 1-5 1000Base-X SFP modules
Type Model
SFP-GE-SX-MM850-A
SFP-GE-LX-SM1310-A
SFP-GE-LH40-SM1310
SFP-GE-LH40-SM1550
1000Base-X SFP
module
SFP-GE-LH70-SM1550
SFP optical
module
SFP electrical
interface module
SFP-GE-T
 Note:
z The types of 1000Base-X SFP modules may be subject to changes without notice.
Consult H3C marketing personnel or technical support personnel to obtain the latest
information about SFP modules.
z For specifications of SFP modules, refer to H3C Low End Series Ethernet Switches
Pluggable Modules Manual.
1.2.2 Rear Panel
I. Schematic diagram
The S3600-28P-SI provides an AC power socket and a grounding screw on its rear
panel, as shown in
Figure 1-2.
