H3C S3600 Series Installation Manual

Installation Manual
H3C S3600 Series Ethernet Switches Chapter 1 Product Overview
1-25
Table 1-11 100Base-X SFP modules
Type Model
SFP-FE-SX-MM1310-A
SFP-FE-LX-SM1310-A
SFP-FE-LH40-SM1310
100Base-X SFP module
SFP-FE-LH80-SM1550
IV. Attributes of the 1000Base-X SFP ports
The S3600-28F-EI provides two 1000Base-X SFP ports numbered 25 and 26 on the
front panel.
SFP modules allow for great flexibility because they are hot swappable and user
configurable.
Table 1-5 lists the available SFP modules.
 Note:
z The types of 1000Base-X SFP modules may be subject to changes without notice.
Consult H3C marketing personnel or technical support personnel to obtain the latest
information about SFP modules.
z For specifications of SFP modules, refer to H3C Low End Series Ethernet Switches
Pluggable Modules Manual.
V. Attributes of the 10/100/1000Base-T Ethernet ports
The S3600-28F-EI provides two 10/100/1000Base-T Ethernet ports numbered 27 and
28 on the front panel. For the attributes of these ports, see
Table 1-7.
VI. Console port
The S3600-28F-EI provides one EIA/TIA-232 compliant Console port for local or
remote switch configuration. For the attributes, see
Table 1-4.
1.6.2 Rear Panel
I. Schematic diagram
The S3600-28F-EI provides an AC power socket, a DC power socket and a grounding
screw on the rear panel, as shown in
Figure 1-10.

H3C S3600 Series Specifications
