H3C S3600 Series Ethernet Switches Chapter 3 Installation
3-1
Chapter 3 Installation
Caution:
When you ask your sales agent to maintain the switch, you must ensure that the
dismantlement-preventive seal on a mounting screw of the switch chassis is intact. If
you want to open the chassis, you should contact the agent for permission. Otherwise,
you will bear any consequence resulted from your actions without permission.
3.1 Mounting the Switch
3.1.1 Mounting the Switch into a 19-Inch Standard Cabinet
You can install the S3600 into a 19-inch standard cabinet in one of the following four
ways:
z Use front mounting ears
z Use front mounting ears and a tray
z Use front mounting ears and rear mounting ears
z Use front mounting ears and guide rails
The installation methods depend on the width and depth of the switch. For the specific
installation methods, see
Table 3-1.
Table 3-1 Installation methods for a switch with a width of 440 mm (17.3 in)
Method
Depth
Use front
mounting
ears
Use front and
rear mounting
ears
Use front
mounting
ears and a
tray
Use front
mounting
ears and
guide rails
260 mm (10.2
in)
√ — √ √
420 mm (16.5
in)
— √ √ √
