H3C S3600 Series Installation Manual

Installation Manual
H3C S3600 Series Ethernet Switches Chapter 1 Product Overview
1-24
LED Mark Color Indicates
ON
The port is connected, and the
device is in an IRF loop fabric.
Green
Flash
Data is being received/sent on
the port
ON
The port is connected, and the
device is in an IRF chain fabric.
Yellow
Flash
Data is being received/sent on
the port
Flashing green
(3 Hz)
A fault occurs to the fabric.
Flashing yellow
(3 Hz)
The port fails POST.
Speed
OFF The port is not connected.
ON
The port is operating in full
duplex mode
Green
Flash
Data is being received/sent on
the port
Flashing yellow
(3 Hz)
The port fails POST.
Duplex
OFF The port is not connected.
OFF No data is being received/sent
10/100/1
000Base
-T Fabric
port LED
—
PoE
Flashing yellow
(3 Hz)
The port fails POST.
III. Attributes of the 100Base-X SFP ports
The S3600-28F-EI provides twenty-four 100Base-X SFP optical ports numbered from 1
to 24 on the front panel.
SFP modules allow for great flexibility because they are hot swappable and user
configurable.
Table 1-11 lists the available 100Base-X SFP modules.
