H3C S5120-SI Series

1-13
To do… Use the command… Remarks
Enter system view
system-view
—
Enter Ethernet
interface view
interface interface-type
interface-number
Enter
Ethernet
interface
view or port
group view
Enter port
group view
port-group manual port-group-name
Required
Use either command.
Enable LLDP trap sending
lldp notification remote-change
enable
Required
Disabled by default
Quit to system view
quit
—
Set the interval to send LLDP
traps
lldp timer notification-interval
interval
Optional
5 seconds by default
Displaying and Maintaining LLDP
To do… Use the command… Remarks
Display the global LLDP
information or the information
contained in the LLDP TLVs to
be sent through a port
display lldp local-information
[ global | interface
interface-type
interface-number ]
Available in any view
Display the information
contained in the LLDP TLVs
received through a port
display lldp
neighbor-information
[ interface interface-type
interface-number ] [ brief ]
Available in any view
Display LLDP statistics
display lldp statistics [ global
| interface interface-type
interface-number ]
Available in any view
Display LLDP status of a port
display lldp status [ interface
interface-type
interface-number ]
Available in any view
Display types of advertisable
optional LLDP TLVs
display lldp tlv-config
[ interface interface-type
interface-number ]
Available in any view
LLDP Configuration Examples
Basic LLDP Configuration Example
Network requirements
As shown in Figure 1-4, the NMS and Switch A are located in the same Ethernet. An MED device and
Switch B are connected to GigabitEthernet 1/0/1 and GigabitEthernet 1/0/2 of Switch A.
Enable LLDP on the ports of Switch A and Switch B to monitor the link between Switch A and Switch B
and the link between Switch A and the MED device on the NMS.
