1-3
To do… Use the command… Remarks
Configure HABP to work in
client mode
undo habp server
Optional
HABP works in client mode by
default.
Displaying and Maintaining HABP
To do… Use the command… Remarks
Display HABP configuration information
display habp
Available in any view
Display HABP MAC address table entries
display habp table
Available in any view
Display HABP packet statistics
display habp traffic
Available in any view
HABP Configuration Example
Network requirements
As shown in Figure 1-2, Switch A is the management device and connects two access devices: Switch
B and Switch C. Configure HABP so that Switch A can manage Switch B and Switch C.
z Configure Switch A as the HABP server, allowing HABP packets to be transmitted in VLAN 2.
z Enable HABP client on Switch B and Switch C.
z On switch A, set the interval to send HABP request packets to 50 seconds.
Figure 1-2 Network diagram for HABP configuration
Configuration procedure
1) Configure Switch A
