H3C S5120-SI Series

2-3
Form Description
source-mac mac-address
Specifies to match the packets with a specified source MAC
address.
The matching criteria listed below must be unique in a traffic class with the operator being AND.
Therefore, even though you can define multiple if-match clauses for these matching criteria or input
multiple values for a list argument (such as the 8021p-list argument) listed below in a traffic class, avoid
doing that. Otherwise, the QoS policy referencing the class cannot be applied to interfaces successfully.
z customer-dot1p 8021p-list
z customer-vlan-id vlan-id-list
z destination-mac mac-address
z dscp dscp-list
z ip-precedence ip-precedence-list
z service-vlan-id vlan-id-list
z source-mac mac-address
To create multiple if-match clauses or specify multiple values for a list argument for any of the matching
criteria listed above, ensure that the operator of the class is OR.
Defining a Traffic Behavior
A traffic behavior is a set of QoS actions. To define a traffic behavior, you must first create it and then
configure actions for the behavior as required in traffic behavior view.
Follow these steps to define a traffic behavior:
To do… Use the command… Remarks
Enter system view
system-view
—
Create a traffic behavior and
enter traffic behavior view
traffic behavior
behavior-name
Required
Drop or send packets filter { deny | permit }
Optional
z deny Dropping packets.
z permit Permitting packets
to pass through.
Redirect traffic to a specified
target
redirect interface
interface-type interface-number
Optional
Defining a Policy
A policy defines the mapping between a class and a traffic behavior.
