4-2

Access Switches

The S5120-SI series can serve as access switches to provide large access bandwidth and high port

density.

Figure 4-2 Application of the S5120-SI series at the access layer

S9500/S7500E

S5120-SI

Access

Core/Aggregation

S5120-SI
