2-13
[Switch-luser-client001] service-type ssh
[Switch-luser-client001] authorization-attribute level 3
[Switch-luser-client001] quit
# Specify the service type for user client001 as Stelnet, and the authentication mode as password.
This step is optional.
[Switch] ssh user client001 service-type stelnet authentication-type password
2) Configure the SSH client
There are many kinds of SSH client software, such as PuTTY, and OpenSSH. The following is an
example of configuring SSH client using Putty Version 0.58.
# Establish a connection with the SSH server
Launch PuTTY.exe to enter the following interface. In the Host Name (or IP address) text box, enter
the IP address of the server (192.168.1.40).
Figure 1-2 SSH client configuration interface
In the window shown in
Figure 1-2, click Open. If the connection is normal, you will be prompted to enter
the username and password. After entering the correct username (client001) and password (aabbcc),
you can enter the configuration interface.
