Page 34
Section 3 Technical Specifications
TYPICAL TECHNICAL DATA
Enclosure: Fiberglass Reinforced Polyester
Dimensions (HxWxD): 1250mm x 750mm x 320mm
Enclosure height may increase to 1750mm, depending on system optional
features.
Weight: 90 kg – 120 kg
Enclosure weight may change depending on system optional features.
Power Consumption: 300 W (VA)
Mains Connection: 115V AC, 60Hz or 230V AC, 50Hz (10%)
Other power options are available on request.
Mains Wire Specification: Number of Cores = 3, Current Rating minimum = 10 Amps, CSA (Cross
Sectional Area minimum) = 1.50mm
2
Signal Wire Specification: Number of Cores = 10 (+2 cores per additional signal), Current Rating
minimum = 1 Amp, CSA (Cross Sectional Area minimum) = 0.22mm
2
.
FEATURES IN DETAIL
Display: High Contrast 40 Character x 16 Line Backlit LCD with CFL Backlight
Data Storage: Previous 9999 analysis data on screen in the microcontroller memory and
storage of data archive for the lifetime of the analyzer in the SD/MMC card
Previous 99 fault data on screen in the microcontroller memory and storage
of fault data archive for the lifetime of the analyzer in the SD/MMC card
SD/MMC Card: Flash memory card for data transfer and for software & configuration updates
Operation: Microcontroller with Membrane Keyboard
Language Options: English, French, German
Other language options are available on request.
INPUT & OUTPUT SIGNALS
Standard Output: One programmable 4-20mA output signal (typically for TOC)
Maximum impedance: 500 ohms
For systems requiring more than six 4-20mA standard outputs, 4-20mA
Output Multiplex option is implemented to provide 4-20mA data for up to 35
output signals.
Digital Output: Two freely programmable system relays (volt free changeover contact with a
current rating of 1Amp at 30V DC)
One system fault relay (volt free changeover contact with a current rating of
1Amp at 30V DC)
Data Transfer Port: SD/MMC Card and serial RS232 Output for Printer, PC or Data Logger
