11
Section 3 Installation
3.1 Overview
The ORBISPHERE 3100 instrument is a self-contained portable analyzer, configured to make
oxygen concentration measurements in gaseous or liquid samples. Up to 5,760 measurement
values can be stored in memory and downloaded to a personal computer for further analysis.
The analyzer is available in 3 different versions (for 4mm, 6mm and 1/4 inch connections).
This section provides all the necessary information to set up the instrument. If you have any
questions or experience any difficulties, do not hesitate to contact your Hach representative
regarding this procedure.
3.2 Unpacking
Carefully remove the instrument and its accessories from the box and packing material, referring
to the packing list included to confirm that everything has been delivered. Please visually
inspect the instrument for shipping damage. If anything is missing or damaged, contact the
manufacturer or your dealer immediately.
A thin protective film has been placed over the screen of the ORBISPHERE 3100 analyzer to
protect it from damage during transportation. For a clear view of the screen, this film must be
peeled off before using the analyzer for the first time.
CAUTION
A secondary more robust protective film has been factory installed over the screen to
protect it from damage and moisture ingress. Under no circumstances should this
protection be removed. If it becomes damaged in any way, please contact your local
Hach representative.
You may want to retain the box and other packing material in case you need to ship the
instrument at a later date. Please dispose safely and ecologically of the box and packing
material (if not being stored for future use).
It is recommended that you read through this manual before carrying out the installation.
3.3 What you have received
If you have ordered a DGK3100-XXXX kit, you will have received the following items:
Quantity Description
1 3100 instrument
1 External power supply adapter with plug
1 3 meters of plastic tubing
1 Tool kit (see Figure 3 on page 12)
1 Instrument carrying strap
1 Operator manual
