37
Main Menu
5.7 Service instrument
5.8 Service O
2
channel
Board Information
This option is useful for troubleshooting purposes and displays information about the mother board,
measurement board and battery
Temperature Checking
This option is useful for troubleshooting purposes and displays the temperature readings of the
measurement board, pigtail, battery pack and sample
Sample Temperature Calibration
You will need a sensor simulator for this option. Follow the on-screen instructions to calibrate the sample
temperature
Miscellaneous
Enable raw data logger
Check the box to enable the capture of raw data which is useful for
troubleshooting purposes
Activate service timer
Check the box to activate the service timer option.
When activated, the instrument will automatically remind the user when the
next sensor service is due.
Enter the Nb of days between services in the box provided. This defines
the due date of the next sensor service.
If activated, select the Reset service timer option each time the instrument
has been serviced. This automatically sets the Last service date parameter
to the current date.
The total uptime of the instrument is displayed at the bottom of the screen.
O2: Calibration Parameters
This option is useful for troubleshooting purposes and will display a number of values associated with the
measurement channel
O2: DC Measurement Parameters
This option is useful for troubleshooting purposes and will display the values of the fluorescent and
reference LED current
O2: AC Diagnostic Parameters
This option is useful for troubleshooting purposes and will display the values of the fluorescent and
reference amplitude and phase, plus the phase shift value
O2: Calibration Timer
Activate calibration timer
Check the box to activate the calibration timer option.
When activated, the instrument will automatically remind the user when the
next sensor calibration is due.
The Last calibration date parameter is shown for information. This is
automatically updated each time a calibration is performed on the sensor.
Enter the Nb of days between calibrations in the box provided. This
defines the due date of the next sensor calibration.
