P/N 53063-30, Manual revision: B
8-10
Using Data Acquisition Features
The operator should remember that the CS5+ device does not control the
data transfer and therefore should verify the following points:
! The output device has been properly connected.
! The output device has actually received the information sent.
! The entire data transfer is correct.
Warning: The physician must consider the information provided by the
CS5+ device as indicative. This information must not be used as the only
indication for medical treatment.
When the Transfer Data information is displayed, the following keys are
available to the operator:
! Start key: initiates the transfer of the selected information to the
selected output device type.
! Stop key: returns the screen display to the data acquisition menu.
! Select key: toggles between the Procedure # and the Device options.
! Arrow keys: used to select a procedure(s) or change settings of the
Procedure # and Device options.
Working with the View Data function
The View Data function allows the operator to visualize information
recorded during previous procedures. When it is selected from the off-line
data acquisition menu, the following information will be displayed:
Figure 8-9, Example of the View Data screen display
Note: The following information will also be displayed if the option was set
in the utilities menu: *EBL Patient (35%), **EPL Patient.
K/&7#3()( $%,.&3?%&#b !
$()/&0)#:R M!L1!;;;@B
ADE2DP#)%(08V&%#!
!
"P3/8'-(4#0&f)#'%,.&3?%&g8#3()("
$%&88#JIRF#),#3/8'-(4#T,-?5&8"
$%&88#ADI$#7*&0#V/0/8*&3"
R()& J,0U!9UM9Uc>
A?%=&%4 I%)*,'(&3/.
D/5&#,V#:08)" !MP!9
A)(%)#)/5& !MP;;
R?%()/,0 1P9B
Q,7-#8/d& 11>#5-
J,3& EHDIJED:+
2&8&%"#K(.??5 !B1#55<=
F%%,%8#.,3&8 9c;L
D,)(-#T,-"#'%,. ;9ML
D,)(-#T,-"#7(8* >M9@
D,)(-#T,-"#%&/0V !1;B
Q,7-8#'%,.&88&3 >
N6%#,V#+IN+#.4.-&8 !
N6%#,V#2DN#.4.-&8 M
e
ee
