P/N 53063-30, Manual revision: B
5-10
Cell Saving using Automatic Operation
DESCRIBING ADDITIONAL AUTO MODE FUNCTIONS
At any time during automatic operation, the operator can advance the sys-
tem to manual operation by pressing the Mode key once. The operator can
also use the Mode key to access an EMERGENCY mode, which may be used
during a procedure to manage high blood loss situations.
In certain situations, the operator will be able to select the concentration op-
tion, used to maintain a high hematocrit end product. Other options exist in
which the operator can modify certain processing parameters, accessible by
pressing the Modify key and entering the Cell Saver setup screen display.
These options will be presented in further detail in the following sections.
Using the EMERGENCY mode
In the EMERGENCY mode, the CS5+ device will process blood at high
speeds while in automatic operation: 800 ml/min during the FILL state, 800
ml/min during the WASH state and 300 ml/min during the EMPTY state. The
pump speed regulation using the effluent line sensor is inactive in the EMER-
GENCY mode.
The EMERGENCY mode is not available when using a 70mL Bowl dispos-
able set.
To enter the EMERGENCY mode when using a Latham bowl disposable set:
" Press the Mode key twice.
" Confirm the selection by pressing the Yes key within 10 seconds.
The following screen will be displayed:
Figure 5-6, Example of a EMERGENCY mode screen display
FJF2[FN+S K,-?5&8#5-
$2I+ 1>MM
2F:NC 9MM
O(8*#T,-?5&P 1MMM
Q,7-8#'%,.&88&3P 1
$?5'#2&=?-(),%#3/8(6-&3
$%&88#JIRF#Z&4#V,%#EHDIJED:+"
$%&88#E22IO#Z&48#),#.*(0=&#T(-?&8"
$?5'#%()&P LMM#5-U5/0
C:GG#QIOG
11>
