P/N 53063-30, Manual revision: B
5-22
Cell Saving using Automatic Operation
SUMMARIZING SETTING VARIATIONS
The following tables summarize the different values for default settings used
throughout the various states of the Cell Saving protocol, depending on the
type of centrifuge bowl in operation.
Table 5-1, pump rate range
State 70mL Bowl Latham 125 Latham 225
FILL 125 ml/min 300 ml/min 600 ml/min
WASH 100-75 ml/min 300 ml/min 500 ml/min
EMPTY 100 ml/min 100-75 ml/min 300-250 ml/min
Table 5-2, Wash volume per cycle
State 70mL Bowl Latham 125 Latham 225
WASH 300 ml 750 ml 1000 ml
Table 5-3, Maximum centrifuge speed
State 70mL Bowl Latham 125 Latham 225
FILL 7000 rpm 5650 rpm 5650 rpm
WASH 7000 rpm 5650 rpm 5650 rpm
Table 5-4, Reservoir sensor level
State 70mL Bowl Latham 125 Latham 225
STANDBY
Initial cycle
400 ml 800 ml 800 ml
STANDBY
Subsequent
cycles
200 ml 600 ml 600 ml
STANDBY
Resume
200 ml 400 ml 400 ml
