Presenting the Cell Saver 5+ System
LISTING THE CELL SAVER 5+ SPECIFICATIONS
The CS5+ device is destined for continuous operation.
Caution: The CS5+ equipment is not suitable for use in the presence of flam-
mable anesthetic mixture with air or with nitrous oxide.
The dimensions and weight of the CS5+ device are as follows:
The following environmental conditions should be respected pertaining to
operation, transport and storage of the CS5+ device:
The electrical specifications for operating the CS5+ device are as follows:
Characteristics Depth (cm) Height (cm) Width (cm)
Device alone
Pole extended 37 189 41
Pole retracted 37 86 41
Device with cart
Pole extended 58.5 230 48
Pole retracted 58.5 127 48
Weight of the device: 34.0 kg
Weight of the cart: 20.4 kg
Conditions Values
Ambient operating temperature 10° C to 27° C
(50° F to 80° F)
Storage temperature –20° C to 50° C
Storage humidity level Maximum relative humidity
rate of 90%, non-condensing
Characteristics
Values
(relative to input voltage)
Input voltage 230 VAC ± 10% 110 VAC ± 10%
Operating current ~1.9 A ~ 2.6 A
Fuse rating F2.5 A @ 250 V F5.0 A @ 250 V
Operating frequency range 50 - 60 Hz 50 - 60 Hz
Maximum leakage current 500 µA 100 µA
