Haemonetics Cell Saver 5+ - Controls and Indicators

P/N 53063-30, Manual revision: B
2-2
Describing the Cell Saver 5+ System Components
Figure 2-1, The Cell Saver 5+ components
1. Centrifuge cover
2. Centrifuge
3. Effluent line sensor
4. Power switch
5. Waste bag weigher
6. Valve and pump
section
7. Keypad
8. Display screen
6.
5.
4.
1.
8.
3.
7.
2.
