1496LE008146B

Event management

List of events in the Error section

No. Text Section Type Unlock Severity Indicated

on the

display

1 E001: L1 current sensor out of service Error Instantaneous Manual High yes*

2 E002: L2 current sensor out of service Error Instantaneous Manual High yes*

3 E003: L3 current sensor out of service Error Instantaneous Manual High yes*

4 E004: N current sensor out of service Error Appearance/end Manual High yes*

5 E005: MHT actuator out of service Error Appearance/end Manual High yes*

6 E006: Critical error 4 Error Appearance/end Manual High yes*

7 E007: Critical error 3 Error Appearance/end Manual High yes*

8 E008: Critical error 2 Error Appearance/end Manual High yes*

9 E009: Rating plug damaged Error Appearance/end Manual High yes*

10 E010: Critical error 5 Error Appearance/end Manual High yes*

11 E011: Critical error 1 Error Appearance/end Manual High yes*

12 E012: Trip unit overheat Error Appearance/end Manual High yes*

19 E019: Level 1 internal error Error Appearance/end Autoreset High Yes

21 E021: Trip unit temperature Error Appearance/end Autoreset Average Yes

22 E022: Trip unit key or button faulty Error Appearance/end Autoreset Average Yes

23 E023: Digital Input faulty Error Appearance/end Autoreset Average Yes

24 E024: Broken Neutral Pole Error Appearance/end Autoreset Average Yes

25 E025: Level 2 internal error Error Appearance/end Autoreset Average Yes

27 E027: Level 3 internal error Error Appearance/end Autoreset Average Yes

28 E028: Level 4 internal error Error Appearance/end Autoreset Average Yes

29 E029: Level 5 internal error Error Appearance/end Autoreset Average Yes

32 E032: Level 6 internal error Error Appearance/end Autoreset Average Yes

33 E033: 24Vexternal power supply lost Error Appearance/end Autoreset Average Yes

34 E034: Rating plug fault Error Appearance/end Autoreset Average Yes

35 E035: Level 7 internal error Error Appearance/end Autoreset Average Yes

36 E036: Level 8 internal error Error Appearance/end Autoreset Average Yes

40 E040: ZSI input activated Error Appearance/end Autoreset Low Yes

42 E042: Level 9 internal error Error Appearance/end Autoreset Low Yes

100 -

E100 to E200: Manufacturing fault Error Appearance/end Autoreset Low Yes

(*) The corresponding error code is notiﬁed in the electronic trip unit HWF failure alarm message.
