580
(3) Description of SW03
SW03
Set the
communication
and central
control address
by dip switch
(*Note 2)
[1] [2] [3] [4] [5] [6] [7] [8]
Communication
address
Central control
address
ON OFF OFF OFF OFF OFF OFF OFF
0
(default)
0
(default)
ON OFF OFF OFF OFF OFF OFF ON 1 1
ON OFF OFF OFF OFF OFF ON OFF 2 2
… … … … … … … … … …
ON OFF ON ON ON ON ON ON 63 63
ON ON OFF OFF OFF OFF OFF OFF 0 64
ON ON OFF OFF OFF OFF OFF ON 1 65
ON ON OFF OFF OFF OFF ON OFF 2 66
… … … … … … … … … …
ON ON ON ON ON ON ON ON 63 127
OFF … … … … … … …
Set the address by wired controller
or automatically (default)
Note 2
• The address must be set by dip switch if central control is used.
• SW03-2=OFF, central control address = physical address +0
• SW03-2=ON, central control address=physical address +64
• The address must be set by dip switch if 0151800113 and 0010451181A or 0151800086 are used together.
(4) Description of SW07
SW07_1
SW07_2
Tdiff correction valve in
AUTO mode
[1] [2]
Tdiff correction valve in AUTO mode
OFF OFF
Tdiff: 0
OFF ON
Tdiff: 1
ON OFF
Tdiff: 2
ON ON
Tdiff: 3 (default)
SW07_3 WIFI control mode
ON
One by one (defaulted)
OFF
One by multi
SW07_4
SW07_5
In heating, inlet air
temp. Tai correction
valve Tcomp2
[4] [5]
Inlet air temp. Tai correction valve Tcomp2 (EEPROM)
OFF OFF
Tai correction valve= 12°C
OFF ON
Tai correction valve= 5°C
ON OFF
Tai correction valve= 8°C
ON ON
Tai correction valve=3°C (default)
SW07_6
Room card.
OEM HRV linkage
ON
Room card is unavailable, HRV linkage is unavailable (default)
OFF
Room card is available, HRV linkage is available
SW07_7
SW07_8
Operation mode
changeover of wired
controller
[7] [8]
Function
OFF OFF
[FAN] [COOL] [DRY] [HEAT]
OFF ON
[FAN] [COOL] [DRY]
ON OFF
[FAN] [COOL] [DRY] [HEAT] [ELECTRIC-HEAT]
ON ON
[AUTO] [FAN] [COOL] [DRY] [HEAT](default)
