Hakko Electronics Monitouch V9 Series Troubleshooting Instructions Supplement

3
1. Error Messages 3-7
Error Handling
166 The function set for the serial port is duplicated.
The sub-item number denotes the ports as
shown below:
0: CN1
1: MJ1
2: MJ2
Specify a unique function (simulator, etc.) for
each port.
174 The I/F driver that does not support ladder
communication is set.
Check that the I/F driver supports ladder
communication.
183 The printer model is not correctly set. Transfer the printer driver suitable for the model
set in the screen program.
184 Printer driver is not found. Transfer the printer driver.
187 Periodical writing or synchronized writing is set
in the device memory map number specified in
the [Logging Server] window.
Check the data in the device memory map.
188 The same device memory address is specified
for writing in the device memory map number
set with periodical writing or synchronized
writing.
Check the data in the device memory map.
189 The Japanese conversion program is not
registered in MONITOUCH.
Transfer the Japanese conversion program.
192* I/F driver setting error
Contact your local distributor.
193* The common data sheet setting is not
registered.
194* The memory card setting is not registered.
195* V-I/O input/output device memory is not
registered.
196 Data stored in the storage device is different. This error may be relevant to the operation for
storing data (screen, 3D parts, etc.) in a storage
device.
Connect a storage device in which data has
been stored correctly using the storage
manager.
199 Multiple functions are assigned to the USB port. Multiple functions are assigned to the USB-B
port. Use the USB-B port only for any of the
following functions: USB simulator, PictBridge
printer, or USB ladder communication function.
201* Total byte count error Contact your local distributor.
207 No video unit is installed. Install an option unit “GUR-00”, “GUR-04”, or
“GUR-10”.
209 PLC ladder data is not registered. Transfer the ladder data.
216 A data sheet includes an item that cannot be
printed.
Recheck the data sheet screen. Remove the
unusable item.
217 The source voltage of the touch panel does not
conform to the specifications.
Check the source voltage. For details on the
power source specifications, refer to the V9
Series Hardware Specifications manual.
301 Recipe setting error Check the recipe settings.
The specified value is outside the permissible
range, or there is a problem with the record
name specification method.
302 The maximum capacity of the alarm server has
been exceeded.
The capacity of DRAM specified under [Internal
Storage Setting] in the [Alarm Server] window
has exceeded the maximum available capacity.
Reduce the number set for [Number of
Monitoring Alarms] or [Number of Data to Save].
Error No. Contents Solution
Sub-item number
Error : 166 (Header : x)
