2-28 2. Local Mode Screen
9-1. Buzzer Setting
The [Buzzer Setting] tab window on the System Setting screen is used to change the buzzer sound.
9-2. Backlight Setting
The [Backlight Setting] tab window on the System Setting screen is used to change the backlight
control setting.
Item Description
Change Buzzer
Setting
Standard
Changes the buzzer sound.
Short
Continuous
OFF
[Buzzer Setting] tab window
After changing the setting,
press the [Apply] switch to
confirm the setting.
Item Description
Change
Backlight
Setting
Action
Always ON
Changes the backlight control setting.
For details on the difference between these actions, refer to the
V9 Series Reference Manual.
AUTO 1
AUTO 2
AUTO 3
Manual
Backlight OFF Time
This item can be set only when [Auto 1], [Auto 2], or [Auto 3] is
selected.
Set the time to elapse until the backlight is turned off.
Control during Backlight Power ON
This item can be set only when [Manual] is selected.
Select the backlight status when the power is turned on and when
the operation mode is changed from STOP to RUN.
[Backlight Setting] tab window
After changing the setting,
press the [Apply] switch to
confirm the setting.
