2-2 2. Local Mode Screen
2. Local Mode Screen
The Local mode screen shows various information about the V9 series, such as system information,
and screen program information, etc.
Also, it works as a system screen for transferring a screen program between a PC and V9 series unit.
To transfer a screen program from a PC to the V9 series unit through serial communication, be sure to
display this screen. (However, it is not necessary if MJ1 is not used.)
Menu icons can be scrolled up and down.
Title of the screen currently displayed
Screen
Menu icons
Clock
Error or warning indication (only when occurring)
Status bar
(only when set to
“display at all times”)
