2-10 2. Local Mode Screen
4. LAN Setting
Pressing [LAN Setting] in the menu icons brings up the LAN Setting screen.
This screen is used to set an IP address of the V9 series unit.
When no LAN cable is connected or a link is not established, the indication of the [LAN Setting] icon is
changed as follows.
Item Description
Restore Screen Data
Settings
Restores the screen program settings after the IP settings were changed on the
V9 series unit.
* When settings are restored, the changes made on the unit are cancelled.
For details on the handling of a screen program changed in Local mode, refer to
page 2-55.
Menu icons LAN Setting screen
Link established Cable disconnected or link not established
Press the [Apply] switch
to confirm the setting.
LAN Setting screen
