2-38 2. Local Mode Screen
When [Display  Storage] Is Selected:
1. When [Display  Storage] is selected, the following screen appears.
The screen program in MONITOUCH is compared with the screen program (in the DSP folder) in
the access folder.
2. Data comparison start
Press the [Start] switch.
3. During data comparison to end of data comparison
During data comparison, the [Start] switch changes to [Transferring] and the [Transferring data...
(Storage)] dialog is displayed.
On successful completion, the following message dialog is displayed. Press the [OK] switch.
* If any other message is displayed, refer to “Message Dialog Displayed during Data Transfer
(between V9 and Storage)” (page 2-42).
Returns to the previous
screen.
Free space in the SD card
Folder name currently
selected
Information of the folder
currently selected
Starts comparison
between MONITOUCH
and the storage device.
Comparing Data comparison completed
