2-48 2. Local Mode Screen
Network Test
This section describes how to execute a network test to check the network status by pinging a
specified IP address from the V9 series unit.
1. Press [I/O Check] in the menu icons and open the [Network Test] tab window.
2. Press the section enclosed in the following figure. The system keyboard appears. Enter the IP
address of the counterpart device targeted for a network test.
3. Press the [Start Test] switch. The test is repeated five times and the result is shown.
Result of the test
Progress of the test
