Hameg CombiScope HM1508-2 Service Manual

75
Subject to change without notice
MANUAL ADJUSTMENT PROCEDURE HM1508-2
29 YP CH 2 Analog DC Offset (Software Adjustment)
28 YP CH 1 Analog DC Offset (Software Adjustment)
– Check that no signal is applied at the BNC connectors.
– Press “DC Offset” function key.
– Press “CH 1” function key for automatic Offset adjustment.
– Wait until the automatic adjustment has been fi nished.
– Continue with item 29.
– Check that no signal is applied at the BNC connectors.
– Press “CH 2” function key for automatic Offset adjustment.
– Wait until the automatic adjustment has been fi nished.
– Press REM pushbutton (EXIT MENU) to return to “Adjust 1 YP” menu and continue with item 30.
– Check that no signal is applied at the BNC connectors.
– Press “VAR Bal.” function key.
– Press “CH 1” function key for automatic Variable Balance adjustment.
– Wait until the automatic adjustment has been fi nished.
– Continue with item 31.
– Check that no signal is applied at the BNC connectors.
– Press “CH 2” function key for automatic Variable Balance adjustment.
– Wait until the automatic adjustment has been fi nished.
– Press REM pushbutton (EXIT MENU) to return to “Adjust 1 YP” menu and continue with item 32.
30 YP CH 1 Analog Variable Balance (Software Adjustment)
31 YP CH 2 Analog Variable Balance (Software Adjustment)
