Hameg CombiScope HM1508-2 Service Manual

76
Subject to change without notice
MANUAL ADJUSTMENT PROCEDURE HM1508-2
– Check that no signal is applied at the BNC connectors.
– Press “Inv. Sym.” function key.
– Press “CH 1” function key for automatic Invert Symmetry adjustment.
– Wait until the automatic adjustment has been fi nished.
– Continue with item 33.
– Check that no signal is applied at the BNC connectors.
– Press “CH 2” function key for automatic Invert Symmetry adjustment.
– Wait until the automatic adjustment has been fi nished.
– Press REM pushbutton (EXIT MENU) to return to “Adjust 1 YP” menu and continue with item 34.
– Check that no signal is applied at the BNC connectors.
– Press “Y Position” function key.
– Press “CH 1” function key for automatic Y Position adjustment.
– Wait until the automatic adjustment has been fi nished.
– Continue with item 35.
– Check that no signal is applied at the BNC connectors.
– Press “CH 2” function key for automatic Y Position adjustment.
– Wait until the automatic adjustment has been fi nished.
– Continue with item 36.
32 YP CH 1 Invert Symmetry (Software Adjustment)
33 YP CH 2 Invert Symmetry (Software Adjustment)
34 YP CH 1 Y Position (Software Adjustment)
35 YP CH 2 Y Position (Software Adjustment)
