Hantek DSO8000E Series User Manual

Basic Operation
DSO8000E Series HandHeld Oscilloscope User Manual 27
Ground Coupling
Use to display a zero-volt waveform. Internally, the channel input is connected with a zero-volt
reference level.
Fine Resolution
In the fine resolution setting, the vertical scale readout displays the actual VOLTS setting. The
vertical scale changes only after you adjust the VOLTS control and set to coarse.
Remove Waveform Display
To remove a waveform from the screen, first push the menu button to display the vertical menu,
then push again to remove the waveform. A channel waveform which is unnecessary to be
displayed can be used as a trigger source or for math operations.
3. VOLTS
Control the oscilloscope to magnify or attenuate the source signal of the channel waveform. The
vertical size of the display on the screen will change (increase or decrease) to the ground level.
Also you may use the key F3 to switch between coarse and fine.
4. MATH MENU: Display the waveform math operations. See the table below for details.
The MATH menu contains source options for all math operations.
Operations
Source Options
Comments
＋
CH1+CH2
Add Channel 1 to Channel 2.
－
CH1-CH2
Subtract the Channel 2 waveform from the
Channel 1 waveform.
CH2-CH1
Subtract the Channel 1 waveform from the
Channel 2 waveform.
X
CH1XCH2
Multiply CH1 with CH2.
/
CH1/CH2
CH1 Dvided by CH2
CH2/CH1
CH2 Dvided by CH1
Position
Set the Math channel’s position.
Scale
Set the Vertical Scale.
FFT
Window
Five types of window available for selection:
Hanning, Flattop, Rectangular, Bartletta and
Blackman
Source
CH1
CH2
FFT zoom
Use the FFT Zoom button to adjust the window
size. Scale: x1, x2, x5, x10.
Vertical Base
dBrms
Vrms
Note: All selected menus are highlighted in orange.
