Basic Operation
DSO8000E Series HandHeld Oscilloscope User Manual 43
Self Cal: The self calibration routine can optimize the precision of the oscilloscope to fit the
ambient temperature. To maximize the precision, you should perform the self calibration once the
ambient temperature changes by 5℃ or more. Follow the instructions on the screen.
Shutdown
Press “UTILITY” key to enter the Utility menu and turn to the page 2/5 and then push the
Shutdown key to set the shutdowm parameter.
Power Off:
1. Press F1 button to select PowerOff.
2. Press F2 to select Time.
3. Press F3 button to confirm.
4. Press F4 button to cancel, and the device will shutdown later.
Restart:
1. Press F1 button to select Restart.
2. Press F3 button to confirm, the device will restart.
Tip: Press any menu button on the front panel to remove the status display and enter a
corresponding menu.
5.5.4 DISPLAY
The waveform display is affected by settings of the oscilloscope. A waveform can be measured
once it is captured. The different styles to display a waveform on the screen give significant
information about it.
There are two modes to display waveforms Single-window and Dual-window. Refer to Horizontal
Controls for more information.
The DISPLAY menu.
YT format shows the vertical voltage in relation to
time (horizontal scale); XY format displays a dot
between CH1 and CH2 each time when a sample is
acquired, where the voltage or current of CH1
determines the X coordinate of the dot (horizontal)
and the voltage or current of CH2 determines the Y
coordinate (vertical). For detailed information, refer
to descriptions on XY format in the following text.
