Overview
DSO8000E Series HandHeld Oscilloscope User Manual 4
Ports and Extentions
2.3
On the right side of the unit,
On the left side of the unit,
Attention: SD card memory should be less than or equal to 4GB.
Power Input DC 12V, 3000mA
Probe calibration signal output 1 KHz, 2Vpp
Type USB-A port for USB flash disk
LAN/Wifi connection port (optional)
Mini USB OTG port
Headphone, not available for this product.
Socket for Micro SD card (optional).
