Basic Operation
DSO8000E Series HandHeld Oscilloscope User Manual 44
0-15 16 ranks adjustable.
Dotted line
Real line
OFF
Off only displays the horizontal and vertical
coordinates at the center graticule on the screen.
0-15 16 ranks adjustable.
Auto
50 Frames
40 Frames
30 Frames
0-15 16 ranks adjustable.
Press keys (except the power button) to wake up
5.5.5 ACQUIRE
Press “UTILITY” key to enter the Utility menu and turn to the page 4/5 and then Push the
ACQUIRE key to set the acquisition parameter.
Acquire waveforms by real-time digital technique.
Rebuild waveforms by equivalent sample technique.
Normal
Peak Detect
Average
Acquire and accurately display most waveforms.
Detect glitches and eliminate the possibility of
aliasing.
Reduce random or uncorrelated noise in signal
display. The number of averages is selectable.
Select the number of averages.
Select the memory depth for different board models.
Normal: For the oscilloscope model with the bandwidth of 100MHz, the maximum sample rate is
1GS/s. For time base with insufficient sample rate, you may use the Sine Interpolation Algorithm to
interpolate points between sampled points to produce a complete waveform record (4K by
default).
To Next Page
