HARDI CONTROLLER 5500
3.5.1.1
ADJUSTMENT
Spec. grav. X.XXX
3.5.2
TOTAL STEP 1
Fill the tank
3.5.2
TOTAL STEP 2
Level sprayer
3.5.2
TOTAL STEP 3
Open all
XXXX mm yyyyyyy
Press
Menu [3.5.2 Total]Menu [3.5.2 Total]
Menu [3.5.2 Total]Menu [3.5.2 Total]
Menu [3.5.2 Total]
This is for calibration of the HARDI Tank Gauge. The guide through the
calibration step by step. A table with up to 100 data points corresponding to
a correction value for each 25mm water level is created.
Method
1. Fill the tank to the maximum level (set in the Extended menu E8.4.1).
2. Press .
3. Press after ensuring the sprayer is level.
4. Open all boom sections and empty the tank. The pulses from the flow
transducer are logged as data points in the Extended menu E8.4.4.
During this session the screen shows:
[xxxx] as the actual water level in millimetres and [yyyyyyy] is the number
of pulses from the flow meter.
