29
HARDI CONTROLLER 5500
3.5.1
TANK GAUGE
Adjustment
3.3.4
END NOZZLES
= XX Boom nozzles
Menu [3.3.4 End nozzles] (Optional)Menu [3.3.4 End nozzles] (Optional)
Menu [3.3.4 End nozzles] (Optional)Menu [3.3.4 End nozzles] (Optional)
Menu [3.3.4 End nozzles] (Optional)
If end nozzles are fitted, set the value to the equivalent coverage by the
boom nozzles.
E.g. End nozzle coverage is 2 metres. This is equal to [04 Boom nozzles].
NOTE: It is important that the volume applied from the end nozzle matches
the volume applied under the boom. This is a comparison of volume per
minute per length. (Litre/min/metre).
When the end nozzle is active, the area covered and volume sprayed is
calculated and registered. If “Active boom size” is displayed, it will show an
increase when the end nozzle is activated.
Menu 3.4 Regulation constant
The sensitivity of pressure regulation valve can be adjusted. Increasing the
regulation constant will give a faster response on the pressure regulation
valve. If the constant is too high, the valve will become unstable. There will
also be excessive wear on the valve. The range is in percent. The factory
default is 50%.
Menu [3.5 Tank gauge]
This menu item is only present if the HARDI Tank Gauge is fitted. Flow
calibration [3.2] must be done before proceeding.
Menu [3.5.1 Adjustment]Menu [3.5.1 Adjustment]
Menu [3.5.1 Adjustment]Menu [3.5.1 Adjustment]
Menu [3.5.1 Adjustment]
The correction factor for the specific gravity of the liquid sprayed can be set.
Default value is 1.000.
For liquid fertilisers, the specific gravity may range up to 1.3 kg/L. The value
in this case would be 1.300.
