HARDI CONTROLLER 5500
Speed transducer for tractor
Note the following if the speed transducer is
fitted to the tractor or vehicle.
The speed transducer is an inductive type. It
requires a metallic protrusion (e.g. bolt head)
to pass by it to trigger a signal.
Recommended distance between protrusion
and transducer is 3 to 5 mm.
Foot pedal remote ON/OFF (optional)
Note the following if the Foot pedal remote is to be fitted.
Remote ON/OFF switch has to be activated from the extended menu at
installation. The HARDI Service centre does this.
NOTE: The main ON/OFF
valve switch at Spray Box
overrides all remote switches.
It must be set to ON for the
optional Remote ON/OFF
switch to function.
The speed/switch harness (A)
is connected to the Controller.
Connect the plug from the
Foot pedal ON/OFF to the correct connector on harness (A).
A speed/switch harness (A)
and extension cable are
needed to connect the speed
transducer to the Controller.
