HARDI CONTROLLER 5500
Tractor installation
Brackets
The supplied tractor pillar
bracket (A) has a hole spac-
ing of 100 and 120 mm.
Check tractor instructions
manual for information re-
garding attachment points.
Three tubes (B) are supplied.
One, two or all 3 may be
used.
They can be bent and short-
ened.
A spacer (C) is also supplied
to allow further attachment
possibilities.
Find the best solution for your
tractor or vehicle.
See the different suggestions
on the next page.
Spray Box
Best placement is to the right of
the driver seat and in combi-
nation with the Controller.
It should be secured from
movement.
Controller
Mount it in the tractor cabin
at a convenient place.
NOTE: An extension cable is
available as an option if the
Controller is to be placed
further away from the Spray
Box. (Ref. no. 261933)
