6 - Maintenance
149
Lubrication Plan - Trailer / Paralift
÷
NOTE! Position 1 and 2 are for suspended sprayers only.
Paralift
There are 3 grease points in each side.
Central Lubrication
The grease nipples are located at the rear of the chassis in
both sides.
Depending on the sprayer setup, there can be 0, 3 or 5 grease
nipples to be lubricated in each side.
Refit the dust caps after lubrication.
