3 - Description
57
RinseTank
One rinsing tank is mounted at the rear of the sprayer behind the main
tank. The tank is made of impact-proof and chemical resistant
polyethylene. It is used for rinsing and flushing of the main tank and
liquid system.
Filling is done via the 1” threaded pipe socket placed in the working area.
The rinsing tank level indicator is placed at the platform.
Capacity: approximately 500 litres.
Clean Water Tank
A clean water tank is integrated into the right side cover. It is accessed for
filling at the sprayer’s right side when entering the platform. The ball
valve (A) for water draining is located behind the grey side cover on the
sprayer’s left side.
The water in this tank is for hand washing, for cleaning of clogged
nozzles etc. Only fill this tank with clean water from the tap.
Capacity: approximately 20 litres.
