3 - Description
70
ChemLocker
A ChemLocker for storage of chemical containers or bags is mounted on
the sprayer’s right side.
μ
ATTENTION! Maximum load is 100 kg or 100 litres.
SafetyLocker
The locker is integrated just above the SmartValves.
It is used for storing non-contaminated protective gear, soap for hand
washing etc. and the FluidBox is accessed here (B).
The locker is split in two compartments for the separation of clean items
from gloves with risk of contamination, and it has room for a soap
dispenser (A).
To open the SafetyLocker, place your hand in the bottom right hand
corner of the side shield (white arrow) and pull to open.
±
WARNING! Although this locker is meant for storing non-toxic
items, it must never be used for storing food, beverages or other
items meant for consumption.
FluidBox
Control box for many sprayer functions.
The FluidBox is accessed from the left side of the sprayer.
It is useful when preparing the sprayer for the spray job.
