Spray Boom
Spray Boom and Terminology
The TWIN FORCE boom (HAZ) is pendulum suspended.
The boom is operated in a strong and stable parallelogram-shaped boom lift (ParaLift).
The boom is fully hydraulic operated with all functions controlled via the direct hydraulic system (DH).
The working width is 18, 20, 21, 24, 27, 28, 30, 32, 33 or 36 metres depending on the delivery.
Standard Boom Features
• Individual tilt of boom wings.
• Negative tilt below horizontal.
• Each boom wing is 2-folded.
• Alternative boom width:
The boom may be used in 1/2-folded boom width.
• Spring-loaded breakaway section.
• Air blowers for TWIN Air system.
These are driven by a built-in hydrostatic transmission
powered by the tractor’s PTO.
The air speed can be adjusted from the tractor cabin.
