8 - Technical Specifications
210
Weight
There are differences up to +/- 300 kg depending on the specifications of the sprayer.
Conditions for the weight indications in the tables below:
• Rated full main tank (nominal volume)
• Full RinseTank, 500 litres
• Folded spray boom
Tank size 3300 litres, wheel size 300/95 R46:
Tank size 4500 litres, wheel size 520/85 R38:
Tank size 5500 litres, wheel size 520/85 R42:
Tank size 7000 litres, wheel size 520/85 R42:
Empty tank Full tank
Boom width Axle load (kg) Drawbar load (kg) Total weight (kg)* Axle load (kg) Drawbar load (kg) Total weight (kg)
18 m 4215 569 4784 7259 1285 8544
20 m 4226 573 4799 7270 1289 8559
21 m 4241 578 4819 7285 1294 8579
24 m 4272 587 4859 7316 1303 8619
27 m 4336 608 4944 7380 1324 8704
28 m 4346 613 4959 7391 1328 8719
30 m 4378 621 4999 7422 1337 8759
Empty tank Full tank
Boom width Axle load (kg) Drawbar load (kg) Total weight (kg) Axle load (kg) Drawbar load (kg) Total weight (kg)
18 m 4111 893 5004 7700 2264 9964
20 m 4123 896 5019 7712 2267 9979
21 m 4139 900 5039 7728 2271 9999
24 m 4171 908 5079 7760 2279 10039
27 m 4237 927 5164 7826 2298 10124
28 m 4248 931 5179 7837 2302 10139
30 m 4281 938 5219 7870 2309 10179
32 m 4371 1028 5399 7960 2399 10359
33 m 4140 1039 5179 7729 2410 10139
36 m 4419 1070 5489 8008 2441 10449
Empty tank Full tank
Boom width Axle load (kg) Drawbar load (kg) Total weight (kg) Axle load (kg) Drawbar load (kg) Total weight (kg)
24 m 5512 1117 6629 9731 2858 12589
27 m 5579 1135 6714 9797 2877 12674
28 m 5590 1139 6729 9809 2880 12689
30 m 5623 1146 6769 9842 2887 12729
32 m 5701 1248 6949 9920 2989 12909
33 m 5709 1260 6969 9928 3001 12929
36 m 5745 1294 7039 9964 3035 12999
Empty tank Full tank
Boom width Axle load (kg) Drawbar load (kg) Total weight (kg) Axle load (kg) Drawbar load (kg) Total weight (kg)
24 m 5617 1033 6650 10986 3124 14110
27 m 5683 1052 6735 11052 3143 14195
28 m 5695 1055 6750 11064 3146 14210
30 m 5728 1062 6790 11097 3153 14250
32 m 5806 1164 6970 11174 3256 14430
33 m 5814 1176 6990 11182 3268 14450
36 m 5850 1210 7060 11218 3302 14520
