3 - Description
3.6
Video Button
AutoSwath Button
Pressing this button turns the AutoSwath feature on and off.
AutoTerrain/AutoHeight/AutoSlant button
The AutoTerrain/AutoHeight/AutoSlant Engage button enables boom height control.
AutoSteer Button
The Engage icon status of the AutoSteer system. The appearance of this icon displays the following:
÷
NOTE! For more information, see “General info” on page 6.1.
Master Switch Status
This bar shows that the Master Switch is active.
Pressing this button takes you to the video screen. Pressing this button repeatedly cycles through the video inputs.
÷
NOTE! For more information on the Video screen, see “Video” on page 3.11.
AutoSwath - ON
AutoSwath - OFF
AutoTerrain/AutoHeight/AutoSlant Engage - Enabled (Automatic Mode)
• When enabled the display beeps three times.
AutoTerrain/AutoHeight/AutoSlant Engage - Disabled (Manual Mode)
• When you disable Automatic Mode on any part of the boom and the display switches to Manual Mode, this
button turns grey and the display beeps twice.
• If less than the full boom remains in Manual Mode, the display will continue beeping twice every three seconds.
AutoSteer is ON and ready to use.
AutoSteer is OFF but ready to engage.
AutoSteer is OFF and unable to engage.
Master Switch - ON (GREEN) Master Switch - OFF (RED)
