VPL400-X: Install Manual
21JULY2023 | 630-00159 B
16
INSTALLATION
VPL400-X: SECTION 4
Figure 4-16
4. Grab the top of the panel and push it back and
forth to check the rigidity. If the panel is loose,
" turn rotating back and
forth between the bolts until the panels are
not loose. See Figure 4-17.
Figure 4-17
INSTALLING A PLATFORM
GATE (IF REQUIRED)
1. Place the gate onto the platform floor and
align the gate tabs with the threaded holes on
the side panels. See Figure 4-18.
Figure 4-18
A furniture dolly can be used to help position the gate
onto the platform.
NOTICE
2.
tabs in gate frame into threaded holes on
" open end wrench
to tighten the screws. See Figure 4-19.
Figure 4-19
