HMX6803+ and OP+HMX+ Installation and Operation Manual 51
Copyright © 2009, Harris Corporation
Chapter 3: Operation
Processing > Embedding
Dolby-E Start Line 12, 9 Specifies the starting video
line of embedded Dolby
bitstreams
• 15 to 54 (1080p, 1080i, and 1080psf
formats) (19)
• 20 to 71 (720p formats) (25)
• 13 to 25 (525i 59.94 format) (15)
• 9 to 30 (625i 50 format) (11)
Audio Group (1-4)
Exists
Reports the presence of the
specified audio group in the
SDI stream
•No
•Yes
Audio Group (1–4)
Embedding Mode
12, B
•
•
12, E
Selects the embedding
mode for the specified
audio group
•Off
• Append (when ADS Clean is set to On)
• OverWrt
• Auto (when ADS Clean is set to Off)
Group 1 Append
Embedding Error
Reports if an append
embedding error has
occurred in the group 1
embedder
•No
•Yes
Group 1 Overwrite
Embed Error
Reports if an overwrite
embedding error has
occurred in the Group 1
embedder
•No
•Yes
Group 2 Append
Embedding Error
Reports if an append
embedding error has
occurred in the group 2
embedder
•No
•Yes
Group 2 Overwrite
Embed Error
Reports if an overwrite
embedding error has
occurred in the group 2
embedder
•No
•Yes
Group 3 Append
Embedding Error
Reports if an append
embedding error has
occurred in the group 3
embedder
•No
•Yes
Group 3 Overwrite
Embed Error
Reports if an overwrite
embedding error has
occurred in the group 3
embedder
•No
•Yes
Group 4 Append
Embedding Error
Reports if an append
embedding error has
occurred in the group 4
embedder
•No
•Yes
Table 3-10. HMX6803+ and OP+HMX+ Parameters (Continued)
Path Parameter Name
Bank/
Switch
Function Options or User Range
