50 HMX6803+ and OP+HMX+ Installation and Operation Manual
Copyright © 2009, Harris Corporation
Chapter 3: Operation
SRC (1–16) Status Reports the state of the
specified sample rate
converter
• Enabled
• Bypassed
Processing > Audio > Delay
Delay Lock 5, 4 Couples fixed delay
controls
• No
•Yes
Aud Ch (1- 32)
(SRC1a - 16b) Delay
5, 5
•
•
7, 6
Adjusts delay for the
specified audio channel
0.000 ms to 1320.000 ms
Processing > Audio > Input Gain
Aud Ch (1- 8) (SRC1a
- 4b) Gain
Adjusts input gain for the
specified audio channel
-36.0 dB to 36.0 dB (0.0 dB)
Processing > Audio > Test Tones
Test Tone 400 Hz
Level
7, 8 Sets the tone amplitude -36.0 dBFS to 0.0 dBFS (18.0 dBFS)
Test Tone 1 kHz Level 7, 9
Test Tone 2 kHz Level 7, A
Test Tone 4 kHz Level 7, B
Processing > Audio > Output Gain
Gain Lock Couples the gain controls
• No
•Yes
Processing > Audio > Output Gain > Embedded Audio
Output Emb Ch (1 -
16) Gain
Adjusts gain for the
specified output embedded
audio channel
-36.0 dB to 36.0 dB
(0.0 dB)
Processing > Audio > Invert > Embedded Audio
Output Emb Ch (1 -
16) Invert
Inverts the selected audio
channel to correct for phase
error
• No
•Yes
Processing > Audio > Mute
Master Mute 7, C Enables muting for all
output audio channels
• Off
•On
Processing > Audio > Mute > Embedded Audio
Output Emb Ch (1 -
16) Mute
Enables muting for
specified output embedded
audio channel
• Off
•On
Table 3-10. HMX6803+ and OP+HMX+ Parameters (Continued)
Path Parameter Name
Bank/
Switch
Function Options or User Range
