HMX6803+ and OP+HMX+ Installation and Operation Manual 53
Copyright © 2009, Harris Corporation
Chapter 3: Operation
Horizontal Phase 14, 3 Adjusts the horizontal
timing
Note: 1080p (50/59.94/60)
ranges apply with the
optional 3G HD license only.
•
0.000
us to 29.616 us (1080p30, 1035i 60, 1080i
60)
•
0.000
us to 14.808 us (1080p 60)
•
0.000
us to 29.646 us (1080p 29, 1035i 59,
1080i 59)
•
0.000
us to 14.823 us (1080p 59)
•
0.000
us to 35.542 us (1080p 25, 1080i 25)
•
0.000
us to 17.771 us (1080p 50)
•
0.000
us to 37.024 us (1080p 24, 1080psf 2)
•
0.000
us to 37.061 us (1080p 23, 1080psf23)
•
0.000
us to 31.987 us (1080i 25_295)
•
0.000
us to 22.209 us (720p60)
•
0.000
us to 22.231 us (720p50)
•
0.000
us to 26.653 us (720p50)
•
0.000
us to 44.431 us (720p30)
•
0.000
us to 44.475 us (720p29)
•
0.000
us to 53.320 us (720p25)
•
0.000
us to 63.518 us (525i 59.94)
•
0.000
us to 63.963 us (625i 50)
Vertical Phase 14, 4 Adjusts the vertical timing
Note: 1080p ranges apply
with the optional 3G HD
license only.
• 0 to 1124 lines (1080p/i/psf)
• 0 to 1249 lines
(1080i 25_295M)
• 0 to 749 lines (720p)
• 0 to 524 lines (525i 59.94)
• 0 to 624 lines (625i 50)
Video Delay 14, 5 Controls the amount of
video delay in frames
• 0-8 frames (HD sync mode)
• 0-10 frames (HD delay mode)
• 0-50 frames (SD)
Audio/Video Align 14, 6 Provides a fixed delay to
the video processing path
to compensate for audio
processing delay
•No
• Yes
Processing > Video > Processing Amplifier
Video ProcAmp
Enable
12, F Enables the video
processing amplifier
•No
• Yes
Y Gain 13, 1 Adjusts gain for the Y
channel
-3.0 to +3.0 dB (0 dB)
Cb Gain 13, 2 Adjusts gain to the Cb
color difference component
-3.0 to +3.0 dB (0 dB)
Table 3-10. HMX6803+ and OP+HMX+ Parameters (Continued)
Path Parameter Name
Bank/
Switch
Function Options or User Range
