54 HMX6803+ and OP+HMX+ Installation and Operation Manual
Copyright © 2009, Harris Corporation
Chapter 3: Operation
Cr Gain 13, 3 Adjusts gain to the Cr color
difference component
-3.0 to +3.0 dB (0 dB)
Y Offset 13, 4 Adjusts offset for the Y
channel
±100.6 mV (0 mV)
Cb Offset 13, 5 Adjusts offset for the Cb
channel
±100.6 mV (0 mV)
Cr Offset 13, 6 Adjusts offset for the Cr
channel
±100.6 mV (0 mV)
White Clip Enable 13, 7 Controls level clipping
according to the White Clip
Level control
• Disable
• Enable
White Clip Level 13, 8 Sets the white clip level 636.9 to 763.1 mV (700 mV)
Black Clip Enable 13, 9 Controls level clipping
according to the Black Clip
Level control
• Disable
• Enable
Black Clip Level 13, A Sets the black clip level -47.9 to +47.9 mV (0.0 mV)
Hue 13, B Adjusts the hue of the
incoming digital video
signal
-180 to +180° (0°)
Processing > Test Pattern Generator
Test Pattern Select 14, 7 Selects the test pattern to
display
• 75% color Bars
• Pathological
• 100% color Bars
Test Pattern Enable 14, 8 Enables the internal test
pattern generator
• Off
•On
Processing > Video > VBI
VBI Control Type Provides a master control
for the VBI line processing
• Individual
•Set All Pass
• Set All Delete
VBI Line (746–750)
Delete
Deletes to black the active
video portion of the
selected VBI line (720p
output only)
•Off
•On
VBI Line (1122–1123)
Delete
Deletes to black the active
video portion of the
selected VBI line (1080p
output only)
•Off
•On
Table 3-10. HMX6803+ and OP+HMX+ Parameters (Continued)
Path Parameter Name
Bank/
Switch
Function Options or User Range
