56 HMX6803+ and OP+HMX+ Installation and Operation Manual
Copyright © 2009, Harris Corporation
Chapter 3: Operation
VBI Line (569–583)
Delete
Deletes to black the active
video portion of the
selected VBI line (1080i
output only)
•Off
•On
Processing > Video > AFD / VI / WSS
Out Aspect Ratio Sets the aspect ratio of SD
output in auto ARCing
control
• 4:3
•16:9
Output > Audio Word Length > Embedded Audio
Audio Ch 1/2 Word
Length
7, D Adjusts the sample
resolution for the selected
output audio channel pair
• 24 bits (default for HD mode)
• 20 bits (default for SD mode)
• 16 bitsAudio Ch 3/4 Word
Length
7, E
Audio Ch 5/6 Word
Length
7, F
Audio Ch 7/8 Word
Length
8, 1
Audio Ch 9/10 Word
Length
8, 2
Audio Ch 11/12 Word
Length
8, 3
Audio Ch 13/14 Word
Length
8, 4
Audio Ch 15/16 Word
Length
8, 5
Table 3-10. HMX6803+ and OP+HMX+ Parameters (Continued)
Path Parameter Name
Bank/
Switch
Function Options or User Range
