HMX6803+ and OP+HMX+ Installation and Operation Manual 57
Copyright © 2009, Harris Corporation
Chapter 3: Operation
Output > Audio Source Select > Embedded audio
Output Emb Ch (1–16)
Source Select
8, E
•
•
9, E
Selects the source for the
specified output channel
Default for each channel is
the corresponding source --
for example, the default for
Output Emb Ch 9 Source
Select is SRC 13a.
• SRC1a
•
•
•
• SRC8b
• SRC1a+1b
• SRC2a+2b
• SRC3a+3b
• SRC4a+4b
• SRC5a+5b
• SRC6a+6b
• SRC7a+7b
• SRC8a+8b
• SRC9a (default for Output Emb Ch 1 Source
Select)
•
•
•
• SRC16b (default for Output Emb Ch 16 Source
Select)
• SRC9a+9b
• SRC10a+10b
• SRC11a+11b
• SRC12a+12b
• SRC13a+13b
• SRC14a+14b
• SRC15a+15b
• SRC16a+16b
• Test Tone 400Hz
• Test Tone 1kHz
• Test Tone 2kHz
• Test Tone 4kHz
•Mute
• EBU R68
•SMPTE RP155
• SRC1a+2a
• SRC1b+2b
• SRC2a+3a
• SRC2b+3b
• SRC2a+4a
• SRC2b+4b
Output > Audio Format > Embedded audio
Output Emb Ch (1–16)
Format Feedback
Reports the AES format
(PCM/non-PCM) of
specified output embedded
audio channel
•PCM
• Non-PCM
• Unknown
Table 3-10. HMX6803+ and OP+HMX+ Parameters (Continued)
Path Parameter Name
Bank/
Switch
Function Options or User Range
