HMX6803+ and OP+HMX+ Installation and Operation Manual 59
Copyright © 2009, Harris Corporation
Chapter 3: Operation
VI Control Controls the embedding of
the VI packet (526/625
only)
• Remove
• Insert Custom
• Convert from AFD
• Pass
• Convert from WSS (valid for 625 input
only)
VI Embed Line Controls the video line
number where the VI
packet gets embedded to in
field 1 (526/625 only)
• 12 to 19 (525) (14)
• 8 to 22 (625) (11)
VI Select Controls the VI code that
gets embedded (526/625
only)
When Out Aspect
Ratio is set to 4:3:
• 16:9 top
• 14:9 top
• >16:9 in 4:3
• 4:3 full
•16:9 l
•14:9 l
•4:3 a 14:9
• 16:9 l a 14:9
• 16:9 l a 4:3
When Out Aspect
Ratio is set to 16:9:
• 16:9 full
• 14:9 p
• >16:9 in 16:9
•4:3 p
• 16:9 prtctd
• 4:3 p a 14:9
• 16:9 a 14:9
• 16:9 a 4:3
SD Out VI with AFD Controls whether the VI
output supports the AFD
upper bits part
• No
•Yes
VI Output (AFD) Indicates current VI output
code AFD part (526/625
only)
•None
• 16:9 top
• 14:9 top
• >16:9 in 4:3
• 4:3 full
•16:9 l
•14:9 l
•4:3 a 14:9
• 16:9 l a 14:9
• 16:9 l a 4:3
• 16:9 full
• 14:9 p
• >16:9 in 16:9
•4:3 p
• 16:9 prtctd
• 4:3 p a 14:9
• 16:9 a 14:9
• 16:9 a 4:3
VI Output (Scan) Indicates current VI output
code Scan part (526/625
only)
•None
• 525 4:3
• 625 4:3
• 525 16:9
• 625 16:9
Table 3-10. HMX6803+ and OP+HMX+ Parameters (Continued)
Path Parameter Name
Bank/
Switch
Function Options or User Range
