WSS Control Controls the embedding of
the WSS packet (625 only)
• Remove
• Insert Custom
• Convert from AFD
• Convert from VI
• Pass
WSS Embed Line Controls the video line
number where the WSS
packet gets embedded to in
field 1 (625 only)
•8 to 23
WSS Select Controls the WSS code that
gets embedded (625 only)
• Full frame
• 14:9 center
• 14:9 top
• 16:9 center
• 16:9 top
• >16:9 center
• Full a 14:9
• 16:9 Anamorphic
WSS Output Indicates current WSS
output code (625 only)
• None
• Full frame
• 14:9 center
• 14:9 top
• 16:9 center
• 16:9 top
• >16:9 center
• Full a 14:9
• 16:9 Anamorphic
Custom On Loss Controls whether to insert
custom code when
upstream code disappears
in code bypass mode
• No
•Yes
Table 3-10. HMX6803+ and OP+HMX+ Parameters (Continued)
Path Parameter Name
Bank/
Switch
Function Options or User Range
